Influence of the Geometrical Configuration of the Iron Shroud on the Optical and Magnetic Properties of the Monopole Symmetric Objective Magnetic Lens
Article Sidebar
Main Article Content
Abstract
This study investigated the effect of varying the geometric configuration of the iron shroud on the magnetic and optical properties of a magnetic lens. The study compared three novel designs of monopole symmetric object magnetic lenses, differing only in the geometry of the iron shroud. The axial magnetic flux density distribution was calculated using Electron Optical Design program. The results indicated that maximum magnetic flux density increases with a decrease in the air gap width, accompanied by a reduction in half-width value. It was found that one of the proposed designs provides an optimal distribution of magnetic flux lines, with no leakage of magnetic field lines outside the pole region. The optical focal properties of lenses were studied using a program based on Finite Element Method to calculate magnetic field distribution, while the optical properties of electromagnetic lenses were analyzed using Optical Properties Program for Electron Magnetic Lenses. The findings revealed that one of the proposed lenses offers the best magnetic and optical properties. A novel and unprecedented magnetic lens design was invented for the first time. The proposed design is distinguished globally by the protrusion of the pole tip into lens structure, Referred to as the Snub Lens.
Article Details
This work is licensed under a Creative Commons Attribution 4.0 International License.
Tikrit Journal of Pure Science is licensed under the Creative Commons Attribution 4.0 International License, which allows users to copy, create extracts, abstracts, and new works from the article, alter and revise the article, and make commercial use of the article (including reuse and/or resale of the article by commercial entities), provided the user gives appropriate credit (with a link to the formal publication through the relevant DOI), provides a link to the license, indicates if changes were made, and the licensor is not represented as endorsing the use made of the work. The authors hold the copyright for their published work on the Tikrit J. Pure Sci. website, while Tikrit J. Pure Sci. is responsible for appreciate citation of their work, which is released under CC-BY-4.0, enabling the unrestricted use, distribution, and reproduction of an article in any medium, provided that the original work is properly cited.
References
1. Musa SJ, Abbas TM. Design and investigate the optical characteristics of single polepiece magnetics lenses. Materials Today: Proceedings. 2023;80:2307-14. https://doi.org/10.1016/j.matpr.2021.06.339
2. Ul-Hamid A. A beginners' guide to scanning electron microscopy: Springer; 2018.
https://doi.org/10.1007/978-3-319-98482-7.
3. Kadhem WJ, Naser BA, Abbas TM. Optimization of asymmetrical magnetic lenses with the aid of EOD program. International Journal of Engineering & Technology. 2018;7(4):3591-4. https://doi.org/10.14419/ijet.v7i4.19326
4. Typke D. Electron-optical research at the AEG Forschungs-Institut 1928–1940. Advances in Imaging and Electron Physics. 220: Elsevier; 2021. p. 1-24.
https://doi.org/10.1016/bs.aiep.2021.08.001
5. AL-Janan MK, AL-Salih R. Design and studying the effect of Polepiece shape on the magnetic and optical properties of the unipolar lens. Tikrit Journal of Pure Science. 2022;27(6):63-9. https://www.iraqoaj.net/iasj/download/a464afca768a40a4
6. Hawkes P. The correction of electron lens aberrations. Ultramicroscopy. 2015;156:A1-A64. https://doi.org/10.1016/j.ultramic.2015.03.007
7. El-Shahat S, Al Amir A, Hassan G. Studies on the effect of pole piece shape for saturated single pole magnetic lens. ANGLISTICUM Journal of the Association-Institute for English Language and American Studies. 2013;3.
8. Khan SA, Jagannathan R. Quantum mechanics of round magnetic electron lenses with Glaser and power law models of B (z). Optik. 2021;229:166303. https://doi.org/10.1016/j.ijleo.2021.166303
9. Ali RS, Hussein MA, Al-Salih RYJ. Optimizing the Effectiveness of Magnetic Lenses by utilizing the Electron Optical Design (EOD) Software. Engineering, Technology & Applied Science Research. 2023;13(6):11980-4.
https://doi.org/10.48084/etasr.6287
10. Al_Salih R. The effect of Air Gap Width on the Focal Properties of Objective Snorkel Lens. Tikrit Journal of Pure Science. 2024;29(2):53-8. https://doi.org/10.25130/tjps.v29i2.1505
11. Kadhem WJ. Obtaining doublet magnetic lenses by synthesis technique. Optik. 2015;126(23):4066-71. https://doi.org/10.1016/j.ijleo.2015.07.204
12. Ismaeel HY, AL-Salih R, Jasim HE. Effect of Outer Polepiece Shroud Geometry on Bipolar Lens and Studying its Properties. Tikrit Journal of Pure Science. 2022;27(4):77-81.
http://dx.doi.org/10.25130/tjps.27.2022.056
13. Aljibory JA, AL-Salih R. Comparison Between the Properties of Three New Designs of Pinhole Magnetic Lens. Tikrit Journal of Pure Science. 2024;29(1):119-27.
https://doi.org/10.25130/tjps.v29i1.1515
14. AL-Janan MK, AL-Salih R. Design and study the effect of inner bore diameter on the magnetic and optical properties of the unipolar lens. Baghdad Science Journal. 2023;20(3):0805.
